  • Dell Poweredge R630 1u Rack Server - 2 X Intel Xeon E5-2660 V4 Tetradeca-core (14 Core) 2 Ghz - 32 Gb Installed Ddr4 Sdram - 1.20 Tb Hdd - 2 X 750 W - 2 Processor Support - 768 Gb Ram Support - Gigabit Ethernet.
  • For best PowerEdge R630 Rack Server Server performance use the maximum amount of 768GB, fill all the slots with the max allowed memory per slot for your Server. What is the warranty on these memory? What if the memory is not compatible?
  • Dell PowerEdge R630 Features Deliver peak performance. Build a blazingly fast transactional database with the R630 24 all-flash drive configuration. Combine the density, scalability and performance of 24 1.8” SSDs with dual-PERC capability to deliver a superior solution that can boost performance by storing an entire database.

With computing capability previously only seen in 2U servers, the ultra-dense PowerEdge R630 two-socket 1U rack server delivers an impressive solution for virtualisation environments, large business applications or transactional databases.

POWEREDGE R630 With computing capability previously only seen in 2U servers, the ultra-dense PowerEdge R630 two-socket 1U rack server delivers an impressive solution for virtualization environments, large business applications or transactional databases. The Dell PowerEdge R630 rack servers support up to: ● Two Intel Xeon E5-2600 v3 or v4 processors ● 24 x 1.8-inch hard drives or 10 x 2.5-inch hard drives or eight x 2.5-inch hard drives ● Four optional NVMe Express Flash PCIe SSDs ● 24 DIMM slots supporting up to 1536 GB of memory ● Two AC or DC redundant power supply units.

• Latest Intel Xeon E5-2600 v3 processors – up to 18 cores
• Up to 24 DIMMs high-capacity DDR4 memory
• Up to 24 1.8” SSDs (23TB)

The PowerEdge R630 server is versatile and highly configurable for a variety of solutions, delivering the latest Intel® Xeon® processor E5-2600 v3 product family, 24 DIMMs of high-performance DDR memory and a broad range of local storage options 24

Get your immediate Dell EMC quote in just under 2 minutes

Use our quote generator today to get the best SAN prices for leading Dell EMC storage solutions that best fit your specific business needs.

Dell PowerEdge R630 Features

Deliver peak performance

Build a blazingly fast transactional database with the R630 24 all-flash drive configuration. Combine the density, scalability and performance of 24 1.8” SSDs with dual-PERC capability to deliver a superior solution that can boost performance by storing an entire database. When combined with the SanDisk® DAS Cache solution, the R630 can help increase OLTP transactions and concurrent usage for latency-sensitive applications, such as e-commerce or financial trading.

Discover greater versatility

Pci

With up to 24 DIMMs of memory, and configured with up to 10 2.5” drives, the R630 can provide a dense, resource-rich midsized virtualization environment to drive business Intelligence applications, from customer relationship management (CRM) to enterprise-resource planning (ERP), while it saves on space, energy and capital costs. You can also increase the speed of data access using up to four NVMe PCIe Express Flash devices with Fluid Cache technology – and share that caching advantage across other networked servers.

Maximise operational efficiency

PowerPoweredge

Quickly and securely monitor or modify critical server settings “at the box” with the iDRAC Quick Sync bezel with embedded near field communication (NFC) capability. Use a handheld device with the bezel to quickly check system health details, and use iDRAC Direct to easily deploy or modify settings across multiple servers with a USB key or laptop, eliminating the potential for configuration errors.

Innovative management with intelligent automation

The Dell OpenManage systems management portfolio includes innovative solutions that simplify and automate essential server lifecycle management tasks – making IT operations more efficient and Dell servers the most productive, reliable and cost effective. Leveraging the incomparable agent-free capabilities of the PowerEdge embedded integrated Dell Remote Access Controller (IDRAC) with Lifecycle Controller technology, server deployment, configuration and updates are streamlined across the OpenManage portfolio and through integration with third-party management solutions. Monitoring and control of Dell and third-party data center hardware is provided by OpenManage Essentials and with anytime, anywhere mobile access, through OpenManage Mobile. OpenManage Essentials now also delivers Server Configuration Management capabilities that automate one-many PowerEdge bare-metal server and OS deployments, quick and consistent replication of configurations and ensure compliance to a predefined baseline with automated drift detection.

Dell Poweredge R630 Power Consumption

FeaturePowerEdge R630 technical specification
Form factor1U rack
Processor sockets2
Dimensions24 x 1.8” and 10 x 2.5” drive configuration: H: 4.28 cm (1.68 in.) x W: 48.23 cm (18.98 in.) x D: 75.51 cm (29.72 in.)
8 x 2.5” drive configuration: H: 4.28 cm (1.68 in.) W: 48.23 cm (18.98 in.) D: 70.05 cm (27.57 in.)
Cache2.5MB per core; core options: 4, 6, 8, 10, 12, 16, 18
ChipsetIntel C610 series chipset
MemoryUp to 768GB (24 DIMM slots): 4GB/8GB/16GB/32GB DDR4 up to 2133MT/s
I/O slotsUp to 3 x PCIe 3.0 slots plus dedicated PERC slot
RAID controllersInternal controllers: PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P
External HBAs (RAID): PERC H830
External HBAs (non-RAID): 12Gbps SAS HBA
Drive baysInternal hard drive bay and hot-plug backplane:
Up to 24 x 1.8” SATA SSD
Up to 10 x 2.5” HDD: SAS, SATA, nearline SAS SSD: SAS, SATA, Up to 4 NVMe PCIe
Up to 8 x 2.5” HDD: SAS, SATA, nearline SAS SSD: SAS, SATA
Maximum internal
storage
HDD: SAS, SATA, nearline SAS SSD: SAS, SATA, NVMe PCIe
24 x 1.8” SSD – up to 23TB via 0.96 TB hot-plug SATA SSD
10 x 2.5” – up to 18TB via 1.8TB hot-plug SAS HDD
8 x 2.5” – up to 14TB via 1.8TB hot-plug SAS HDD
Embedded NIC4 x 1Gb, 2 x 1Gb + 2 x 10Gb, 4 x 10Gb
Power SuppliesTitanium efficiency 750W AC power supply; 1100W DC power supply; Platinum efficiency 495W, 750W, 1100W
